If I were planning a delivery-only kitchen in Dubai, I’d start with flow, approvals, and temperature control - not equipment. That’s because even a small setup can cost AED 80,000 to AED 150,000, while a larger multi-brand site can pass AED 500,000, so layout mistakes get expensive fast.
Here’s the short version:
- I’d map a one-way food path: receiving → storage → prep → cooking → packing → dispatch
- I’d keep raw, cooked, packing, wash-up, and rider pickup separate
- I’d plan for the main approvals from day one: fit-out permit, DCD fire NOC, and DM food safety permit
- I’d size cooking, holding, and cold storage for peak order times, not average trade
- I’d build a separate rider handover area so dispatch does not block the kitchen
- I’d fix ventilation, grease trap access, fire suppression, power, and gas before ordering equipment
A few numbers shape the whole plan. Hot holding needs to stay at 63°C or above. Raw meat storage should sit at 0°C to 5°C. Equipment should have 150 mm floor clearance or be sealed to the floor. Walls need washable finishes up to at least 2 m. And authority plus consultant fees for a 100–200 sq. m cloud kitchen can land around AED 15,000 to AED 29,500.
Cloud Kitchen Layout Flow: From Receiving to Dispatch in Dubai
Quick comparison
| Area | What I’d focus on | Key numbers |
|---|---|---|
| Layout | One-way flow and no crossover | Receiving to dispatch in one direction |
| Food safety | Split raw, cooked, and packing zones | Hot holding 63°C+ |
| Cold storage | Separate raw meat and dairy storage | Meat 0°C–5°C, dairy 0°C–4°C |
| Approvals | DM/DDA/Trakhees, DCD, DM food permit | Fees: AED 15,000–29,500 for 100–200 sq. m |
| Cleaning access | Legs or sealed bases, coved edges | 150 mm clearance, walls to 2 m |
| Ventilation and fire | Type I hoods, duct route, suppression | Manual pull within 5 m |
My view is simple: in Dubai, a delivery kitchen works best when the floorplan is built around compliance, dispatch speed, and heat control from the start.
sbb-itb-19c3c9a
Step 1: Map Compliance and HACCP Zones Before Choosing Equipment
Start with zoning. In Dubai, your layout affects approval, hygiene, and how fast orders move out the door. Dubai Municipality enforces a one-way food flow. That means each step must move forward, from receiving to dispatch, with no backtracking and no crossover between raw and cooked paths. Your zoning needs to satisfy approval rules and keep dispatch moving at pace.
Build a Linear Food Flow from Receiving to Dispatch
Use a fixed sequence: Receiving → Storage → Prep → Cooking → Packing → Dispatch. Each zone should lead straight into the next. Staff should never carry raw proteins back through a cooked food area, and delivery riders should stay out of the production floor.
This one-way setup also helps during rush periods. When stations are placed in the order people actually work, the kitchen feels more like an assembly line and less like a traffic jam.
Plan HACCP-Friendly Separation for Raw, Cooked, and Packing Areas
Physical separation isn’t optional. Keep raw meat, poultry, seafood, and dairy prep away from ready-to-eat prep by using dedicated counters or physical barriers, along with separate tools and clear labels for each area. Packing should sit away from wash-up and waste zones, and rider pickup should be kept separate from the production floor.
In a fast-moving, multi-brand kitchen, staff can’t depend on memory alone. Colour-coded chopping boards, bins, and prep tools make separation easier to follow under pressure. For allergen control, each station also needs dedicated tools and clear labelling.
Account for Dubai Municipality and Civil Defence Design Requirements
A few practical rules will shape your floorplan from day one. Hands-free taps, such as elbow- or foot-operated units, need to be installed in prep areas, with at least one station for every five food handlers. Walls must have smooth, washable finishes up to a minimum height of 2 metres, and floor-to-wall edges should be coved so dirt doesn’t build up in corners. Equipment must either stand on legs with at least 150 mm of floor clearance or be sealed all the way to the floor.
Temperature control also needs to be built into the plan. Raw meat storage must stay between 0°C and 5°C, dairy between 0°C and 4°C, and hot holding must remain at a minimum of 63°C. Don’t treat these as inspection-only numbers. They should shape the layout early. Place refrigeration and hot holding on the floorplan before you lock in the equipment list, because the floorplan will decide equipment size and placement.
Step 2: Design the Layout for Fast Production and Clean Dispatch
Turn your zone map into a floorplan that gets orders from prep to dispatch with as few steps as possible. That plan should show which stations belong side by side, which need separation, and exactly where dispatch should sit.
Choose a Layout Pattern That Matches Menu Volume and Unit Size
The main delivery kitchen layouts are assembly line, zone-based, and island.
| Layout Pattern | Best For | Pros | Cons |
|---|---|---|---|
| Assembly Line | High-volume single concepts (burgers, bowls, fried chicken) | Fastest flow; least staff movement; one-direction process | Less flexible for diverse menus |
| Zone-Based | Multi-brand kitchens running 3–8 brands | Separates brands; reduces mix-ups; improves accountability | Requires more floor space |
| Island | Compact commercial units | Compact and flexible | Can become crowded during peaks |
Single-brand kitchens usually perform best with an assembly line setup. It keeps the process moving in one direction and cuts wasted movement. If you're pushing out burgers, bowls, or fried chicken at high volume, this layout tends to make the most sense.
Multi-brand kitchens need more separation. A zone-based layout with shared receiving, cold storage, and central prep - plus separate brand assembly counters - helps cut order mistakes and makes ownership clearer for each team. Once you lock in the pattern, the next job is simple: place stations in the same order staff use them.
Position Prep, Cooking, Holding, and Packing Stations in Working Order
Each station should follow the working sequence, step by step. Put refrigeration right beside prep tables. Keep frying close to packing so hot items can go straight into bags without a long walk across the kitchen.
In a multi-brand setup, each brand needs its own assembly counter. A burger station should stay separate from a pizza station, even if both use the same central cookline. That bit of separation can save a lot of hassle during a lunch rush.
Packing should lead straight into the handover zone. The shorter that path, the less dwell time you get, and the better chance you have of keeping food at the right temperature.
A KDS with station printers also helps during peak service. When orders stack up at once, it keeps items clear at each station and cuts missed components.
Create a Separate Rider Pickup Zone to Reduce Congestion
Dispatch should move just as smoothly as production. Set up the rider pickup zone as a separate handover point with its own entrance. Include a dedicated handover counter, pickup shelving, and an order-check station. Heated holding racks should also sit in this area to help keep food warm while drivers arrive.
That separation matters. If riders crowd the same space as kitchen staff, things can get messy fast. A clean handoff usually means better temperature control and fewer order errors.
Before you lock the layout, test it against a peak-order rush. That kind of dry run is often where bottlenecks show up, especially around dispatch. Also keep the dispatch area away from drainage maintenance points to avoid odour problems during cleaning.
Step 3: Select Equipment That Supports Volume, Food Safety, and Maintenance
Once the layout is locked in, the next step is choosing equipment that can handle peak demand, follow storage rules, and still leave room for servicing and cleaning.
Core Cooking and Production Equipment for Continuous Service
Size the cookline for busy periods, not average output. If the kitchen gets slammed during lunch or dinner, average volume won’t save you.
A 10-tray combi oven on three-phase power (380–415V) can support batch production during peak service. Pair that with a six-burner gas range, and place fryers beside the packing line to cut dwell time between cooking and dispatch.
For cold storage, use T3-rated refrigeration built for UAE heat. Raw meat and dairy should stay in separate units at their required temperatures. T1 compressors, which are rated only up to 32°C, aren’t suitable for UAE conditions. Before ordering any large unit, check that the site has enough power capacity.
Once the main production equipment is sized, move to the next layer: holding and packing tools that keep food at the right temperature and help orders go out correctly.
Holding, Chilling, and Packing Equipment for Delivery Quality
Hot holding cabinets must keep food at a minimum of 63°C to meet Dubai Municipality standards. In practice, these cabinets sit in the dispatch zone and bridge the gap between production and rider pickup.
If the kitchen uses a cook-chill model, install a blast chiller that can bring food down to 3°C within 90 minutes. That supports food safety and helps maintain delivery quality. Temperatures should be recorded every four hours.
Packing equipment matters more than it first appears. Sealers, thermal bags, and label printers help secure packs, hold temperature, and cut dispatch errors. They protect the food during the short but critical window between the line and rider handover.
The last equipment layer covers grease control and wash-up. It’s not glamorous, but it plays a big part in keeping the kitchen compliant during daily cleaning.
Grease Management, Wash-Up, and Custom Fabrication Needs
Grease trap sizing should match the kitchen’s footprint and concept mix. Dubai Municipality requires a minimum of 50 litres for kitchens under 50 sq. m., 100 litres for kitchens between 50–150 sq. m., and 250+ litres for larger sites.
A multi-brand cloud kitchen running two or three concepts will often need a 1,500–2,000-litre grease trap, with weekly cleaning. Placement matters here. If the trap is tucked under a fixed counter, even routine cleaning becomes a headache. Put traps and service points where technicians can reach them without shifting fixed counters. Mandatory quarterly cleaning is much easier when access is planned from day one.
For extraction, Type I hoods with grease filters and collection troughs are required above any equipment that produces grease and smoke, such as fryers and grills. Type II hoods are only enough for steamers and dishwashers.
Use Grade 304 stainless steel for all food-contact surfaces and custom-fabricated items. Where possible, choose leg-mounted equipment to make cleaning faster around grease-producing stations.
Step 4: Finalise Space Planning, Ventilation, and Fire Safety for Dubai Conditions
Once the equipment list is locked, the fit-out needs to protect airflow, fire safety, and day-to-day access for cleaning and servicing.
Divide Space by Zone Rather Than Filling the Room with Equipment
Start with zoning the kitchen, then place equipment inside each area. That approach keeps the layout workable instead of turning the room into a tight maze.
Each piece of cooking equipment needs at least 600 mm clearance from combustible walls. Equipment should either stand on 150 mm legs so staff can clean underneath, or be fully sealed to the floor with no gap. Floor-to-wall junctions should also use coved profiles to cut down dirt traps, which is a standard DM inspection point.
Design Ventilation and Grease Duct Routes for Heat, Smoke, and Odour Control
Hood position and duct routing should be fixed before the walls are closed. If that part is left too late, changes get messy and expensive.
For high-heat cooking like fryers, wok ranges, and griddles, exhaust face velocity should reach 0.75–1.0 m/s. Light-duty cooking needs a minimum of 0.5 m/s. Supply air should replace 80–85% of exhaust air so the kitchen stays under slight negative pressure. Ducting should discharge outside the building, and service access must stay in place for cleaning and maintenance. In plain terms: lock the duct route before closing the walls.
Integrate Fire Protection and Utility Planning from the Start
Type I hoods need automatic wet-chemical suppression, manual pull stations within 5 m, and nozzle placement that meets code. Updated DCD 2026 specifications also require revised chemical agent quantities and specific nozzle positioning angles for deep-fat fryers.
Mechanical, electrical and plumbing drawings should be finalised before equipment is ordered. Large units such as combi ovens and dishwashers need three-phase power at 380–415 V. If the kitchen runs on gas, specify Natural Gas (20–25 mbar) or LPG (28–37 mbar) at factory level so certification is not voided by field injector changes. Getting these calls made early can help avoid revision rounds that may delay the project by 4–8 weeks.
The table below sums up the main infrastructure options for delivery kitchens, based on compliance load and day-to-day fit:
| Design Choice | Compliance Complexity | Operating Considerations | Best Fit |
|---|---|---|---|
| Gas Cooklines | High - requires Civil Defence gas certification and specific injector configuration | High heat output; needs heavy-duty ventilation and gas detection sensors | High-volume production units, wok-heavy menus |
| Electric Cooklines | Moderate - requires 3-phase power and ESMA/ECAS certification | Lower ambient heat; easier to clean; energy efficient | Compact cloud kitchens, pastry, and healthy bowl concepts |
| Type II Hoods | Low - heat and vapour extraction only | No suppression needed; simpler ducting | Dishwashers and steamers |
FAQs
How much space does a delivery-only kitchen need in Dubai?
In Dubai, delivery-only kitchens usually need 15 to 30 square metres of dedicated cooking space. Since there’s no dine-in area, the layout needs to stay compact and efficient, with every metre doing a job.
Aisles should be at least 1.2 metres wide to meet the Dubai Universal Design Code. Day to day, kitchen capacity depends less on total floor area and more on how well the space is divided between storage, prep, cooking, and dispatch.
What approvals should I secure before starting the fit-out?
Before starting the fit-out, secure the key approvals required in Dubai. These usually include:
- initial approval from the Department of Economy and Tourism (DET)
- approval of your kitchen layout plans from Dubai Municipality or the relevant local authority, such as Trakhees or DDA
- a fire safety NOC from Dubai Civil Defense
How can I reduce rider congestion during peak hours?
Separate the dispatch zone from the main kitchen floor. Create a dedicated space for order checks and pickup, with shelving and heated holding racks, so riders can collect orders without stepping into the production area.
This cuts down on traffic between kitchen staff and outside riders, which helps reduce disruption and keeps service moving. If you can, add a separate entrance too. During busy delivery periods, that small change can ease bottlenecks and keep the flow much smoother.
